1. Model overview
  2. CS

CS
Errors and omissions excepted.

Models


  • The CS150 Edition 5 model sports the powerful Bosch Performance Cargo Line motor and can be fitted with either a 545 or 725 watt-hour battery.
  • In addition to the large ‘Extended Front Rack’, the Edition 5 model of the CS150 is now also fitted with a sturdy rear rack as standard.
  • Take advantage of the Ca Go-Smart deal and save 1,100 Euros!


CS150 Equipment

Drive & Steering
  • Bosch Performance Cargo Line
  • Bosch PowerPack 545
  • Enviolo CVP Trekking Nabenschaltung
  • Enviolo Twist Display Pro
  • KMC chain
  • Cable steering with double cable guide

Suspension
  • SR Suntour Cargo 20" Mobie 34

Cockpit
  • Ergotec stem Swell RE; Level 6
  • Ergotec Riser Bar 70, Level 6
  • Ergon GP10
  • Bosch LED Remote

Saddle
  • Satori Trident Ca Go Custom
  • Ergon ST10

Tyres
  • Schwalbe "PickUp" 65x406

Brake System
  • Magura MT5, 4-piston, 203 mm (front)
  • Magura MT4, 2-piston, 203 mm (rear)

Lighting System
  • Supernova Mini 2
  • Supernova TL-Z with integrated reflector

Others
  • SKS Ca Go Custom
  • Ursus Ca Go Custom Bipod Stand
  • Ca Go Custom Extended Front Rack
Matching accessories
€4,890.00

PowerPack 725Wh

PowerPack 725Wh

PowerPack 545Wh

PowerPack 545Wh

Bosch KIOX 300 Display

  • Compact, high-resolution colour display
  • Intuitive operation via LED remote
  • Splash-proof and dust-proof (IP54)
  • Range indicator for all riding modes
  • Navigation function via eBike Flow app
  • Continuous function expansion via eBike Flow App

Bosch SmartphoneGrip

  • Secure smartphone holder for Bosch eBike Smart System
  • Use of the smartphone as a display
  • Attachment via modular display holder
  • Smartphone power supply via the e-bike on-board network via micro-USB cable or inductively
  • Wireless system connection and control via LED Remote
  • Integrated charge control display
  • Dimensions: 65.2 mm x 75.8 mm x 32.9 mm
  • Weight: 75 g

Bosch Connect Module

  • E-bike GPS Tracker (only for e-bikes with Bosch Smart System motor from MY 2022)
  • Simple plug-n-play installation on the motor by the specialist dealer
  • Precise location transmission in the eBike Flow app
  • Theft detection & acoustic alarm system
  • Own, integrated battery

CS Rear Rack & Lock

  • Stable luggage rack
  • MIK-HD interface
  • Ortlieb QL-3 system
  • Abus ring lock
  • Maximum load: 27 kg

Bosch PowerPack 725

  • High energy supply with compact size and low weight
  • 725 Wh Bosch battery
  • 50 % charge: ca. 2.3 hours, 100 % charge: approx. 6 hours
  • Dimensions: 344 x 95 x 100 mm
  • Weight: 4 kg

CS Extended Front Rack

  • Space for a large 600x400 mm Euro Box, standard hardware store folding boxes or smaller loads
  • Lightweight Foamlite construction with sturdy tubular frame
  • The length and width of the CS are not changed by the Extended Front Rack

CS Floormat

  • Protects against moisture, dirt and scratches
  • Non-slip
  • Precise fit
  • Easy to clean

CS Utility Bag

  • Space for your lock, straps, etc.
  • Weather-resistant, water-repellent EVA shell
  • Integrated combination lock

CS Center Rack Protection Cover

  • Small size, easy to store
  • Stable fit thanks to metal applications
  • Privacy, rain and weather protection

CS Bike Garage

  • Lightweight, water-repellent and sturdy material
  • Protects against the weather, dirt and prying eyes
  • tool-free assembly in seconds

CS Cargo Soft Bag

  • Perfect fit for the Centre Load Rack
  • Lockable with cable lock (not included)
  • Can be unfolded for more interior space (28 to 36 litres)

Ca Go Belts

  • 2 sturdy securing straps made from 100% polypropylene
  • Length: 2.5 meters
  • Intended lashing force: 100 daN (corresponds to approx. 100 kg weight force)
